This dataset contains:
(1) Sample plot 1;
（2) Sample plot 2;
（3) GPS point coordinates and plot description of biandukou quadrat;
（4) Rough - pre test flat mouth 1;
（5) Rough - pre test flat mouth 2;
This data can provide basic data for the development and verification of microwave remote sensing algorithms. The data set mainly includes the original photos of roughness measurement at each sampling point of biandukou quadrat 1 and biandukou quadrat 2 during the pre-test in the upstream cold area, and the calculation results of surface height standard deviation (CM) and correlation length (CM). The roughness data is collected by digital photography, and then the top of each spoke in the photo and the four corners of the board are manually digitally sampled under ArcView software to obtain the image coordinate value. After geometric correction, the height of each spoke is calculated, and then the surface height standard deviation and surface correlation length are calculated according to the formula.
Each quadrat of flat mouth is 3grid × 3grid, 30m for each grid × 30m。 The calculation formula is shown in pages 234-236, Volume II, microwave remote sensing. In the roughness data file, the first is the sample name, and then the data body includes 4 columns (number, file name, standard deviation and correlation length). Each file name, i.e. TXT file, corresponds to a sampling photo, and the standard deviation (CM) and correlation length (CM) represent the roughness. This is followed by the length of 101 spokes in each photo, which belongs to the intermediate result to check and correct.
The roughness data is collected by digital photography, and then the top of each spoke in the photo and the four corners of the board are manually digitally sampled under ArcView software to obtain the image coordinate value. After geometric correction, the height of each spoke is calculated, and then the surface height standard deviation and surface correlation length are calculated according to the formula. The calculation formula is shown in pages 234-236, Volume II, microwave remote sensing
In the roughness data file, the first is the sample name, and then the data body includes 4 columns (number, file name, standard deviation and correlation length). Each file name, i.e. TXT file, corresponds to a sampling photo, and the standard deviation (CM) and correlation length (CM) represent the roughness. This is followed by the length of 101 spokes in each photo, which belongs to the intermediate result to check and correct.
Good data quality
This work is licensed under a
Creative
Commons Attribution 4.0 International License.
CSTR:11738.11.ncdc.NIEER.2021.1728
10.12072/ncdc.NIEER.db1798.2022
