Method and apparatus forsimulating and designing structure parameters of air-corecoil and electronic device
发布时间：2024-01-15
元数据
名 称
Method and apparatus forsimulating and designing structure parameters of air-corecoil and electronic device
科技资源标识
CSTR:11738.16.NCDC.XDA14.PT6204.2024
数据共享方式
开放下载
摘 要
The present invention discloses a method and apparatus forsimulating and designing structural parameters of an air-corecoil.The method for simulating and designing structuralparameters of the air-core coil includes: building an imped-ance function of the air-core coil according to a structuralparameter variable, the air-core coil being of a differentialstructure and being wound in a completely parallel windingfashion; building an index function of the air-core coil bycalculating an equivalent bandwidth,sensitivity and anequivalent noise power spectrum by means of the impedancefunction.The method is intuitive, and makes calculation ofthe optimized technological and structural parameters easierand more convenient, thus reducing the amount of calcula-tion and shortening the calculation time.
底青云,康利利,王中兴,刘志尧,张天信,尹雄. Method and apparatus forsimulating and designing structure parameters of air-corecoil and electronic device. 国家冰川冻土沙漠科学数据中心(http://www.ncdc.ac.cn), 2024. https://cstr.cn/CSTR:11738.16.NCDC.XDA14.PT6204.2024.
