Realization and Characterization of a Bulk-Type All-Silicon High Pressure Sensor
发布时间：2024-01-08
元数据
名 称
Realization and Characterization of a Bulk-Type All-Silicon High Pressure Sensor
科技资源标识
CSTR:11738.14.NCDC.XDA14.PP5652.2024
DOI
10.1109/JMEMS.2017.2786730
数据共享方式
开放下载
摘 要
Distinct from conventional diaphragm-type pressure sensors, a silicon-based bulk-type high pressure sensor has been analyzed, realized, and characterized. External hydrostatic pressure acting on the sensor is converted to a biaxial compression inside an all-silicon encapsulated vacuum cavity. The stress anisotropy is analytically modeled and numerically simulated. The biaxial compression is measured using two pairs of piezoresistors oriented to optimally utilize the anisotropy of silicon piezoresistance. An improved pressure seal in the test-package allowed extended testing of the sensor up to a pressure of 200 MPa and a temperature of 175 °C. Reported also is a zero-offset of the sensor, largely attributed to the tensile stress induced by the insulating cover oxide after cooling from the high-temperature dopant activation anneal.
陈燕铃,林德泉,陆磊,张德强,郭士超,张轶铭,周显良,王文. Realization and Characterization of a Bulk-Type All-Silicon High Pressure Sensor. 国家冰川冻土沙漠科学数据中心(http://www.ncdc.ac.cn), 2024. https://cstr.cn/CSTR:11738.14.NCDC.XDA14.PP5652.2024.
陈燕铃,林德泉,陆磊,张德强,郭士超,张轶铭,周显良,王文. Realization and Characterization of a Bulk-Type All-Silicon High Pressure Sensor. 国家冰川冻土沙漠科学数据中心(http://www.ncdc.ac.cn), 2024. https://www.doi.org/10.1109/JMEMS.2017.2786730.
