Can AFM be used to measure absolute values of Young's modulus of nanocomposite materials down to the nanoscale?
发布时间：2024-01-08
元数据
名 称
Can AFM be used to measure absolute values of Young's modulus of nanocomposite materials down to the nanoscale?
科技资源标识
CSTR:11738.14.NCDC.XDA14.PP4372.2024
DOI
10.1039/d0nr02314k
数据共享方式
开放下载
摘 要
At present, a technique potentially capable of measuring values of the Young’s modulus at the nanoscale is atomic force microscopy (AFM) working in the indentation mode. However, the question if AFM indentation data can be translated into absolute values of the modulus is not well-studied as yet, in particular, for the most interesting case of stiff nanocomposite materials. Here we investigate this question. A special sample of nanocomposite material, shale rock, was used, which is relatively homogeneous at the multi-micron scale. Two AFM modes, Force-Volume and PeakForce QNM were used in this study. The nanoindenter technique was used as a control benchmark for the measurement of the effective Young’s modulus of the shale sample. The indentation rate was carefully controlled. To ensure the self-consistency of the mechanical model used to analyze AFM data, the model was modified to take into account the presence of the surface roughness. We found an excellent agreement between the average values of the effective Young’s modulus calculated within AFM and the nanoindenter benchmark method. At the same time, the softest and hardest areas of the sample were seen only with AFM
Liu Yuke. Can AFM be used to measure absolute values of Young's modulus of nanocomposite materials down to the nanoscale?. 国家冰川冻土沙漠科学数据中心(http://www.ncdc.ac.cn), 2024. https://cstr.cn/CSTR:11738.14.NCDC.XDA14.PP4372.2024.
Liu Yuke. Can AFM be used to measure absolute values of Young's modulus of nanocomposite materials down to the nanoscale?. 国家冰川冻土沙漠科学数据中心(http://www.ncdc.ac.cn), 2024. https://www.doi.org/10.1039/d0nr02314k.
