DEM Data Based Stratigraphic Visualization Modeling（基于 DEM 数据的地层可视化建模）
科技资源标识
CSTR:11738.14.NCDC.XDA14.PP6137.2024
DOI
10.2991/amms-17.2017.49
Share type
开放下载
摘 要
We proposes a three-dimensional visualization modeling method of multilayer stratum by the DEM data, including the longitude, latitude and depth information. The interactive environment is mainly supported by a Pythonembedded plotting library, Matplotlib. We adopted the DEM data to create the upper and lower surfaces of each stratum, which is the core component for stratum construction. To reinforce the visual perception of three-dimensional effect, we chose the appropriate angle of light and shaded the surfaces with geophysical map. The challenging point of this research is located in the creation of the solid between adjacent surfaces. Our solution is to extract the surface edge points according to the data storage structure, and generate 4 side surfaces for each stratum based on the polygon plotting principle. Consequently, a three-dimensional visualization model of multilayer stratum has been created
吴谦霖,朱丹丹,王陈晨,叶智慧,陈冬. DEM Data Based Stratigraphic Visualization Modeling（基于 DEM 数据的地层可视化建模）. National Cryosphere Desert Data Center(http://www.ncdc.ac.cn), 2024. https://cstr.cn/CSTR:11738.14.NCDC.XDA14.PP6137.2024.
吴谦霖,朱丹丹,王陈晨,叶智慧,陈冬. DEM Data Based Stratigraphic Visualization Modeling（基于 DEM 数据的地层可视化建模）. National Cryosphere Desert Data Center(http://www.ncdc.ac.cn), 2024. https://www.doi.org/10.2991/amms-17.2017.49.
