Deep Detection Acoustic Reflection of Borehole side While Drilling Based on Impulse Source with Microscope Technique
发布时间：2024-01-19
元数据
名 称
Deep Detection Acoustic Reflection of Borehole side While Drilling Based on Impulse Source with Microscope Technique
科技资源标识
CSTR:11738.14.NCDC.XDA14.PP6314.2024
数据共享方式
开放下载
摘 要
Single-well acoustic wave deep detection has developed rapidly and has become one of the most popular technologies. It has potential application value in the balance between detection depth and detection resolution.According to the actual background of acoustic wave deep detection, the influence of acoustic source excitation frequency, horizontal position of reflection interface and reflection interface inclination angle on the amplitude of reflected wave under the condition of drilling impulse source is studied by using finite element numerical simulation software. The research shows that the optimal operating frequency of the impulse source detection instrument is 7 kHz. Under this source frequency, the borehole-side reflectors of 50°~90° can be effectively detected. The conventional source-distance drilling instruments can cover the borehole-side reflectors within 10m. The impulse source is applied to the field of deep detection while drilling for the first time, which can meet the requirements of different depths of detection and resolution. It can provide reference for the development of the instrument while drilling based on impulse source.
Zhou Jing,Xiong Liu,Fu Hao. Deep Detection Acoustic Reflection of Borehole side While Drilling Based on Impulse Source with Microscope Technique. 国家冰川冻土沙漠科学数据中心(http://www.ncdc.ac.cn), 2024. https://cstr.cn/CSTR:11738.14.NCDC.XDA14.PP6314.2024.
